FET1.5-XX-500-04R PCB SCREW TERMINAL BLOCK

  • PCB spring terminal block Rated current: 12 A Rated voltage: 300 V Wire range: 26-14 AWG Pitch: 5.0 mm/5.08 Mounting: Wave soldering
  • Poles
    2
    3
    4
    7
Products weight: Package quantity:

Details

UL/CUL
Use GroupBCD
等级 Use Group300--
Rated Current [A]12-10
Wire Range [AWG]26~14
Dielectric Voltage-Withstand1.6KV

IEC
Overvoltage CategoryIIIIIIII
Contamination Class322
Rated Voltage [V]250400630
Rated Current [A]17.517.517.5
Impulse withstand voltage [KV]444
Conductor cross section [mm²]0.5~1.5

Material
Insulation MaterialPA66
Flame relardant ratingUL94-V0
Conductor MaterialCopper alloy
Plating of conductor surfaceSn plated

Other Data
Pitch/Poles [mm]/[P]5.0,5.08/2~24
Stripping Length [mm]5~6
Screw/Torque(Max)[N.m] M3/0.5
Operating temperature [℃]-40~+105
Soldering temperature250℃/5S
Pin dimensions [mm]0.6*0.9
PCB Hole Diameter [mm]∅1.3
